Deckmount VT60 BiPAP

Basic Specifications & Features — Deckmount VT60 ST BiPAP

Based on manufacturer brochure and reseller specs:

Feature Specification / Detail

Model / Name Respirare BiPAP VT60 ST

Therapy Modes CPAP, S (spontaneous), T (timed), ST (spontaneous/timed), VAPS (Volume Assured Pressure Support)

Pressure Range - CPAP mode: 4–20 cm H₂O <br>- IPAP: up to 30 cm H₂O <br>- EPAP: up to ~28 cm H₂O

Tidal Volume (VT) Adjustable: 150 – 1800 ml

Respiratory Rate / Backup 4 – 45 breaths/min (has a backup rate for ST / VAPS)

Ramp / Rise Time ‒ Ramp: off or 5–45 min <br>‒ Rise Time: 100–900 ms

Trigger Sensitivity 1–5 levels (for in-trigger, to detect patient breathing)

Humidifier Built-in heated humidifier with levels (1–5)

Display 2.8-inch LCD screen

Noise Level Very quiet — < 28 dBA

Alarms / Safety Leak alert (beep), likely other safety alarms.

Auto On / Off Automatically starts when mask is put on; stops when removed. (“i-Mode”)

Power / Battery – Input: 100–240V AC <br>– Built-in 8-hour backup battery (per some resellers)

Dimensions / Weight ~ 280 × 140 × 95 mm ; weight ~ 1.7 kg (with humidifier)

Operating Conditions Temp: +5°C to +35°C, Humidity: 10–95% RH non-condensing, Altitude: up to ~2,591 m

Standards / Regulatory Complies with IEC 60601-1-1, IEC 60601-1-2, IEC 80601-2-12, CDSCO Class II

Warranty 2 years (repair / replacement) per manufacturer.

---

✅ Pros / Strong Points

Versatile therapy modes: Because it supports ST and VAPS, it’s suitable for patients who need more advanced ventilatory support (not just simple BiPAP).

Quiet operation: At under 28 dBA, it’s fairly silent, which helps for sleeping / home use.

Auto On / Off: Makes it user-friendly, no need to press power every time.

Portable / Compact: Relatively small and lightweight for a BiPAP with humidifier.

Integrated data logging: Supports monitoring and data tracking (1 day, 7 day, 31 day, etc.) per spec sheet.

Safety: Leak alerts; well-specified power / battery backup.
