BMC GII Y30T BiPAP

Key Specifications & Features

Model: RESmart GII Y-30T BiPAP

Operating Modes: CPAP, S, S/T, T

Pressure Range:

IPAP: 4–30 cm H₂O

EPAP: 4–30 cm H₂O (depending on source)

Ramp Time: 0–60 minutes

Rise Time (Inhalation/Exhalation): 1–6 levels (adjustable)

Trigger Sensitivity: 8-step inhalation-exhalation trigger

Exhalation Relief (“Reslex”): Off / Level 1–3

Display: 3.5-inch color LCD

Humidifier:

Integrated heated humidifier (optional in some packages)

5-step humidity level control

Water chamber capacity: ~ 350 mL (according to some specs)

Noise Level: ≤ 30 dB

Monitoring / Alarms:

Monitoring of tidal volume (Vt), respiratory rate, minute ventilation, and leak

Alarms for disconnection, high/low pressure, etc.

Data / Connectivity:

SD card for data storage

iCode QR / QR-based data management for compliance tracking (some versions)

Dimensions & Weight:

Without humidifier: ~170 × 180 × 118 mm

With humidifier: ~290 × 180 × 134 mm

Weight: ~1.5 kg (without humidifier) / ~2.5 kg (with humidifier)

Power Supply: 100–240 V AC, 50/60 Hz

Operating Conditions:

Temperature: 5–35°C

Humidity: 15–93% non-condensing
