Deckmount VT30D Auto CPAP

Key Specifications & Features

Therapy Modes: CPAP, Auto CPAP

Pressure Range: 4 – 20 cm H₂O

Sound / Noise Level: < 28 dBA ± 2 dBA

Leak Compensation: Auto-leak compensation to maintain required pressure

Peak Flow: 240 L/min

Ramp Time: Off / Auto / 5 – 45 min

Expiratory Pressure Relief (“A-Flex”): On / Off, 3 levels

i-Mode (Auto On/Off): The device auto-starts when mask is worn, and auto-stops when removed.

Humidification: Integrated heated humidifier, levels 0–5, up to ~80 °C

Display: 2.8-inch LCD

Data Reporting / Memory: Therapy data can be stored / reviewed for 1 day, 7 days, 31 days, up to 6 months, and 1 year.

Alarms: Leak alert

Dimensions: 280 × 140 × 95 mm (when humidifier is attached)

Weight: ~1.7 kg (with humidifier)

Power: 100-240V input adapter

Battery Backup: Supports external battery (2–8 hours)

Operating Conditions:

Temp: +5 °C to +35 °C

Humidity: 10–95% RH (non-condensing)

Altitude: up to ~2,591 m

Supplemental Oxygen: Can support up to 4 L/min in CPAP mode.

Air Filter: Washable pollen filter

Tubing: Standard 19 mm

Warranty: 2 years

Standards / Safety: Meets IEC 60601-1-1, IEC 60601-1-2, IEC 80601-2-12, CDSCO Class II.

---

✅ Pros / Strengths

Very quiet operation (<28 dBA) — good for light sleepers.

Auto CPAP mode allows pressure to adjust automatically, which can be more comfortable / effective for varying apnea severity.

A-Flex (pressure relief) helps make exhalation more comfortable.

Integrated humidifier improves comfort, especially if you feel dry throat / nose.

i-Mode (auto on/off) makes it easy to use — less fiddling with buttons.

Good data management (multiple time scales) — useful for tracking therapy.

Portable size: relatively compact and not too heavy.

Longer external battery support: 2–8 hours, so can work in places with power cuts (if you have an appropriate battery).
